High-Performance Linear Actuators - EAS / EAC Series

  • Reversed Motor, Guide and Electromagnetic Brake Options Available
  • Built-in Controller or Pulse Input Type Drivers
Starting from
$734.40
Available to Ship:
8 Business Days
EAC / EAS Linear Actuators

Motion Control Products
Motor Sizing Tools
Index TableBall & Lead ScrewBelt Actuator

Designed to make sizing a motor for your application faster and easier, these new sizing forms calculate the necessary torque, speed, stopping accuracy, and the system inertia that is also important to consider when selecting a proper motor for the application.

Click here to learn more.

Service & Support
Service & Support

Products and technology are only valuable when coupled with skilled people and services to support them. At Oriental Motor, our focus is characterized by Total Service Before and After you purchase. We offer short lead-time, for one unit or larger quantities. Our Technical Support Team is available 15 hours a day, via phone, e-mail or live chat and offer advanced industry knowledge to help size and recommend the ideal motion products. Please call on us to meet your motion control needs.

On Demand TrainingOn-Demand or Live Training Seminars

Learn about our technology advantages.

  • 800 Technical Support
  • Engineering & Application Engineering
  • Motor Sizing & Selection
  • Repair Services



New Products
Compact Linear Actuators
DRL II Series Compact Linear Actuators
  • Standard or Guide type
  • Ground or Rolled ball screw
  • Significantly fewer parts
  • Reduced assembly time
  • Repetitive Positioning Accuracy:
    • Ground Ball Screw = ±0.0003 mm (±0.00012 in.)
    • Rolled Ball Screw = ±0.01 mm (±0.00039 in.)

DRL II Series with Built-in Controller
DRL II Series Compact Linear Actuators with Built-in Controller
  • Standard or Guide type
  • Ground or Rolled ball screw
  • Significantly fewer parts
  • Reduced assembly time
  • Repetitive Positioning Accuracy:
    • Ground Ball Screw = ±0.0003 mm (±0.00012 in.)
    • Rolled Ball Screw = ±0.01 mm (±0.00039 in.)

AC Input Axial Flow Fans
AC Input Axial Flow Fans
  • Brushless Motor
  • Low Power Consumption
  • 4.72 in. (120 mm) Frame Size

Long-Life AC Input Axial Flow Fan
Long-Life AC Input Axial Flow Fans
  • 100,000 Hour Life Expectancy
  • Alarm Types Available
  • 6.30 in. (160 mm) up to 7.87 (200 mm) Frame Sizes

Alarm Type DC Axial Flow Fan
Alarm Type DC Input Axial Flow Fans
  • High Performance
  • Built-in Alarm Circuit
  • 2.44 in. (62 mm) up to 6.77 (172 mm) Frame Sizes

Splash Proof Axial Flow Fans
Splash Proof DC Input Axial Flow Fans
  • IP55 Rated
  • Stall Alarm
  • 3.15 in. (80 mm) up to 4.69 in. (119 mm) Frame Sizes

Variable Speed PWM Control Axial Flow Fans
Variable Speed DC Input Axial Flow Fans
  • PWM Control
  • Pulse Sensor
  • 2.36 in. (60 mm) up to 4.72 (120 mm) Frame Size

High Torque Brother AC Gear Motors
High Torque AC Gear Motors
  • Parallel Shaft, Right-Angle Shaft or Right-Angle Hollow Shaft
  • Single-Phase 115, 220, 230 or Three-Phase 208/230/460 VAC
  • Lead Wire or Terminal Box
  • IP65 Types
  • Brake Options

Enclosure Fan Modules
Enclosure Fan Modules
  • Complete Ventilation Packages:
    Fan + Cover + Filter
  • Exhaust or Suction Type
  • IP2X, IP4X, IP43 or IP55 Type
  • AC or DC Input

CVK Series Stepper Motors and Drivers
1.8° CVK Series Stepper Motor Packages
  • Up to 50% more torque in the low speed range
  • Reduced vibration and noise
  • Frame sizes:
    0.79 in. (20 mm) up to 2.22 in. (56.4 mm)
  • 24 VDC

CVK Series Stepper Motors and Drivers
0.36° / 0.72° CVK Series Stepper Motor Packages
  • Lowest vibration and noise
  • Up to 85% more torque in the mid and high speed ranges
  • Frame sizes:
    1.10 in. (28 mm) up to 2.36 in. (60 mm)
  • 24 VDC

EAS Series Linear Actuators
EAS Series Linear Actuators with Built-in Controller (Stored Data)
  • All-in-one Stepper Motor and Linear Slide
  • RS-485 Communications
  • 24/ 48 VDC, Single-Phase 100-120 or Single-Phase 200-240 VAC

EAC Series Linear Actuators
EAC Series Linear Actuators with Built-in Controller (Stored Data)
  • All-in-one Stepper Motor and Linear Cylinder
  • RS-485 Communications
  • 24/ 48 VDC, Single-Phase 100-120 or Single-Phase 200-240 VAC

EAS Series Linear Actuators
EAS Series Linear Actuators
  • All-in-one Stepper Motor and Linear Slide
  • Pulse Input Type
  • 24/48 VDC, Single-phase 100-115 or Single-Phase / Three-Phase 200-230 VAC

EAC Series Linear Actuators
EAC Series Linear Actuators
  • All-in-one Stepper Motor and Linear Slide
  • Pulse Input Type
  • 24/48 VDC, Single-phase 100-115 or Single-Phase / Three-Phase 200-230 VAC

BMU Series Brushless DC (BLDC) Motors
BMU Series Brushless DC (BLDC) Motor Speed Control System
  • High performance, easy-to-use at an affordable price
  • Speed Control Range: 80 ~ 4000 r/min
  • Single-phase 100-120 or Single-Phase / Three-Phase 200-240 VAC

RKII Series Stepper Motors with Built-in Controller
RKII Series Stepper Motors
with Built-in Controller
  • PLC or PC based control
  • Up to 31 units daisy chained
  • Single-phase 100-120 or 200-240 VAC

RKII Series Stepper Motor & Pulse Input Driver
RKII Series Stepper Motor & Pulse Input Driver Packages
  • Standard & Geared Type Stepper Motors
  • Accepts 1.8° or Other Pulse Inputs
  • Single-phase 100-120 or 200-240 VAC

Click to view more New Products
